Coring with a drill, coring with a rope, hammering up and down, gravity impact, etc. Used for Geological exploration. Solitary rock formations, karst formations, broken zones, weak interlayers, deep holes over 50 meters, etc.

• Variable speed Motor, adjustable speed and torque continuously. High volumetric efficiency

• New Electrical Control System - 7-inch display, drilling data acquisition and remote monitoring

• Turbocharged Diesel Engine with strong power, high reliability and low fuel consumption

• Lightweight Mud Pump, compact and lightweight design, capable of circulating mud and high-viscosity drilling fluids.

• Crawler Equipped with a dual-speed crawler chassis, remote-controlled operation, highly manoeuvrable. Maximum traveling speed up to 4.0 km/h, and maximum climbing angle up to 25°

• Drilling angle 45°-90°

• Foldable Mast - Simple and reliable structure, easy operation

• Hydraulic Automatic Standard Penetration Tester (Optional) with automatic striking, automatic counting and automatic data transmission

• Protection Mesh - Protect operators to ensure worker safety.

• Integrated Hydraulic System - Multifunctional integrated valve block, high reliability, low pressure loss

  Standard:

  • Variable Speed Motor

  • 7-inch Display Screen

  • Wireless Remote Controller

  • Rotation Unit Sideways Sliding Device

  • Adjustable Drill Rig Support Seat

  • Foldable Mast

  • Safety Protection Mesh

  • Foldable Drill Pipe Hanger



  Optional:

  • Hydraulic Automatic Standard Penetration Tester

  • Steel Tracks

  • Mud Recycling System

  • BW100-7 Hydraulic Mud Pump
